M16 x 50 x 3.3mm Form G Flat Construction Washer, Metric, HV140 Mild Steel, BZP, BS 4320

M16 Form G Flat Washer

Form G flat washer designed for secure, reliable fastening in a wide range of applications. Designed with a 17.27mm internal diameter to fit M16 threaded fasteners.

A large heavy-duty washer with an outer diameter that’s up to 3 times the internal diameter which sees them used across many applications. The large external diameter ensures optimal load distribution, enhances joint performance, and protects surfaces from damage.

A versatile washer used by professionals and DIY enthusiast for numerous applications. These include construction, building projects, engineering assemblies, automotive, DIY and home improvement.

M16 Form G Flat Washer Specifications

• Size (TD): To fit M16 - 16mm
• Outer diameter (D): 50mm max
• Internal diameter (ID): 17.27mm max
• Thickness (T): 3.3mm max
• Material: HV140 Mild Steel
• Finish: Bright Zinc Plated


Part of a larger range of washers available from Fusion Fixings.
