M12 (15mm) x 50mm JCP Drop-In Anchor, Zinc & Yellow (DBM12)

M12 Drop-in Anchor

M12 drop-in anchor designed to offer a permanent threaded socket within non-cracked concrete or other masonry surfaces.

A permanent socket which allows for the removal and replacement of the fixing if needed and comes with a zinc & yellow passivation for medium resistance to corrosion.

This secure hold is obtained by the expansion of the end of the drop-in anchor within the substrate. Once installed, the correctly sized screw or bolt can be screwed into the anchor effectively securing the material to the substrate.

Setting and expansion of the drop-in anchor can be guaranteed by using the correct M12 setting punch.

Simply drop the anchor into the correctly sized hole, place the setting punch against plug inside the anchor within the hole, and hit with a hammer to set the anchor.

This action forces the internal plug forward which expands the drop-in anchor against the walls of the substrate, securing it in place.

Non-lipped drop-in anchors can be fitted flush or deeper into the substrate but once set they are set. Commonly used in construction and engineering projects where it's necessary to secure objects like structural beams, pipes, or equipment to a concrete surface.

M12 drop-in anchor specification

• Thread diameter (D): M12 - 12mm
• Length (L): 50mm
• Drill hole size: 15mm
• Internal threaded length: 18mm
• Material (M): Steel
• Finish: Zinc & Yellow


Drop-in anchors offer a reliable internally threaded socket for use with corresponding screws to effective attach various materials to concrete or other masonry surfaces.

Effective and easy to install sees them used by DIY enthusiasts and professionals alike.
